If you want to use your Videohub in mission critical environments, you can even connect Videohub control panels to routers via a dedicated Ethernet switch. You can plug your Universal Videohub router into your existing computer network. You can even select the backlighting brightness, as well as if you want a "take" button. You can select where the Videohub is on your network, as well as how many destinations you want on the panel. Blackmagic, Universal, VideoHub, 300, Power Supply, 450w, Videohub 72, Blackmagic Universal VideoHub 300 Power Supply JavaScript seems to be disabled in your browser.
Connect to the built-in USB connection and then run the software. The Blackmagic Universal Videohub 450W Power Card allows you to add up to three blocks of external 12V power supply (not included) to your Univeral Videohub.
#Universal videohub 450w power card software#
You can customize buttons, sources, and destinations using the Windows and Mac software included with each Videohub control panel (control panel not included with Universal Videohub). The Universal Videohub 72 comes with 18 x SDI interface cards and one 72 x 72 crosspoint card that enable switching. For maximum flexibility, interface cards are all the same size and fit both Universal Videohub 72 and Universal Videohub 288, which is great if you need to switch to a different frame size in the future. The SDI and optical fiber interface cards also support 16 channels of embedded SDI audio. The Universal Videohub Deck Control Cable breaks out to 4 separate RS-422 connections.
#Universal videohub 450w power card plus#
You can hot-swap interface cards while working live without the need to power down the router.Įach SDI and optical fiber SDI interface card features 4 inputs and 4 outputs, plus a breakout cable port for deck control. Universal Videohub frames come in a choice of two sizes that let you expand your router up to either a 72 x 72 or 288 x 288 crosspoint sizes. The Universal Videohub lets you build your own broadcast quality 3 Gb/s SDI and optical fiber SDI router for SD, HD, 4:4:4 and 2K video formats. You can also customize your own control units with the available SDK (Software Development Kit). Ethernet connection permits control of the router via hardware control surface, tablet, or computer. All outputs are re-clocked for smooth video display. This allows you to mix and match cards, so your router can be either all SDI, all optical-SDI, or a mix of SDI and optical-SDI.Įach interface card features auto standards detect, so you can connect your video, and the card will auto detect the video signal. Interface cards are available with either SDI or Optical SDI connectors supporting 3 Gb/s video signals. The router supports up to 18 modular interface cards, with each card supporting four inputs and four outputs.
#Universal videohub 450w power card full#
The Blackmagic Design Universal Videohub 72 Full Router enables crosspoint routing between 72 inputs and 72 outputs.
